DX 5000 CD
Description
Main Features
Frequency range 28.000 - 29.700 MHz HF 10 Meter Band AM/FM/SSB/CW
Frequency Range 25.615 - 30.105 MHz (DR-5000 Export version)
Backlighted LCD Display (amber color) with 7-digit frequency readout
2-Digit Channel Number readout
6 Frequency Bands, 60 Channels (programmable) in each band
RF Power max 12W AM/CW, 40W FM, 40W SSB
Digital S/RF Meter, RG Gain control, RF Power control
CW jack fitted a t back of radio
Scan/SC List, Dual Watch, EMG, RB, NB/ANL, LOCK, LCD Off, TOT, HI-Cut
Dynamic Microphone with UP/DOWN/AQ (Auto Squelch) controls
Quick UP/Quick DOWN frequency selection
PA (Public Address) circuit
S/SQL (manual or automatic Squelch control)
Radio is fully PC programmable (with optional PC Interface Cable)
Antenna Connector UHF SO239
Temperature Range -15/+50 °C
Input Voltage 13.8V (15.9V max / 11.7V min) - 9A max at 40W SSB PEP
Dimension : cm 28 x 25 x 6 / Weight : kg 2.8
Version 6
Frequency range 28.000 - 29.700 MHz HF 10 Meter Band AM/FM/SSB/CW
Frequency Range 25.615 - 30.105 MHz (DR-5000 Export version)
Backlighted LCD Display (amber color) with 7-digit frequency readout
2-Digit Channel Number readout
6 Frequency Bands, 60 Channels (programmable) in each band
RF Power max 12W AM/CW, 40W FM, 40W SSB
Digital S/RF Meter, RG Gain control, RF Power control
CW jack fitted a t back of radio
Scan/SC List, Dual Watch, EMG, RB, NB/ANL, LOCK, LCD Off, TOT, HI-Cut
Dynamic Microphone with UP/DOWN/AQ (Auto Squelch) controls
Quick UP/Quick DOWN frequency selection
PA (Public Address) circuit
S/SQL (manual or automatic Squelch control)
Radio is fully PC programmable (with optional PC Interface Cable)
Antenna Connector UHF SO239
Temperature Range -15/+50 °C
Input Voltage 13.8V (15.9V max / 11.7V min) - 9A max at 40W SSB PEP
Dimension : cm 28 x 25 x 6 / Weight : kg 2.8
Version 6
